Pro-Ject Phono Box Phono Preamplifier

$161 $179
By Project

Description

Moving Magnet/Moving Coil Phono preamp with line output

Most of today's amplifiers are built without a specific phono cartridge input. The Phono Box is an ideal phono preamplifier for these hi-fi systems, accepting both MM and MC cartridges. The analogue output of the Phono Box can easily be connected to the line-input of your amplifier.

Features:

  • Preamplifier for MM or MC with switch on rear panel
  • Best buy classic
  • "Green" DC power supply (< 1 watt standby power)
  • Precise RIAA equalisation
  • Low noise ICs
  • Output stage with ultra-low impedance
  • Gold-plated RCA sockets
  • Small size for installation near record player


    Specifications:

    Input Impedance, MM 47 kohms / 120 pF
    Input Impedance, MC 100 ohms / 120 pF
    Gain, MM 40 dB
    Output Voltage (Typically), MM 300 mV / 1 kHz at 3 mV / 1 kHz
    Gain, MC 60 dB
    Output Voltage (Typically), MC 300 mV / 1 kHz at 0.3mV / 1 kHz
    Max. Output 9.5 V (1 kHz)
    Noise Floor, MM 94 dBA
    Noise Floor, MC 75 dBA
    THD, MM 0.01%
    THD, MC 0.05%
    RIAA-Equalisation Curve Accuracy 20 Hz - 20 kHz / Max. 0.5 dB
    Outboard Power Supply 18 V / 200 mA DC, Suitable for Your Country's Mains Supply
    Standby Power Consumption < 1 Watt
    Power Consumption 20 mA DC
    Dimension W x H x D 103 x 36 x 104 (115 mm with Sockets)
    Weight 570 g
