Onkyo TX-NR7100 AV Receiver

$1,999
By Onkyo

Description

The first in the series to offer both 9 channels and built-in, ready-to-use DIRAC Live® Room Correction, the Onkyo TX-NR7100 9.2 Channel THX® Certified AV Receiver brings new meaning to the phrase, “home movie night.” The DIRAC Live® Room Correction offers improved musical staging, clarity, dialog, and deeper bass, while the additional two channels create a 5.1.4 Dolby Atmos® immersive surround sound experience.

Featuring three HDMI-out options, the TX-NR7100 AV receiver delivers uncompressed HDMI 8K/4K transfer at 40 Gbps, increasing the bandwidth over its predecessors. Put through thousands of tests to obtain the coveted THX Certification, this SMART AV Receiver™ delivers an unparalleled movie, music, and gaming experience to your home.

  • DIRAC Live Room Correction: Built-in, state-of-the-art digital room correcting technology improves overall audio performance. Dirac Live automatically calibrates sound in your room using our smartphone app and included microphone or the Dirac Live desktop or laptop application* and a 3rd party USB mic (not included). Dirac Live unlocks your loudspeakers’ full potential in any listening space and delivers a uniquely pristine listening experience.
    * Device must be connected to the internet and the same network as your AVR.
  • Discrete Zone 2 HDMI Switching: Set up different high-definition entertainment options with up to an 8K60 resolution
  • IMAX Enhanced: Bring larger-than-life home. Using DTS: X® technology, IMAX Mode delivers lMAX Enhanced content as the filmmakers intended. IMAX Enhanced films are available to stream or own on Ultra HD Blu-ray™
  • Enhanced Gaming:  Own your opponents with HDMI 2.1 enhancements for gamers: 4K/120Hz HDR pass-through enables ultra-fast motion -VRR (Variable Refresh Rate) eliminates lag, stutter, and frame-tearing for fluid gameplay. – ALLM (Auto Low Latency Mode) optimizes latency from source to screen – QFT (Quick Frame Transport) limits lag for a smoother experience.
  • Stream your favorite music: Use Works with Sonos 1, Chromecast built-in™, AirPlay 2, and DTS Play-Fi®; includes Spotify®, Amazon Music, Pandora®, TIDAL, Deezer, or TuneIn streaming services
  • THX® Certified Select Theater-Reference Sound: Guarantees the same reference volume of a commercial theater in rooms where the screen-to-seat distance is about 12 ft. (3.5 m).
  • Roon plays to thousands of USB, Airplay, and Chromecast devices, but Roon-tested devices are profiled by the Roon team to ensure simple setup and effortless daily use. If you own a Roon Tested device, you can have the confidence that you will enjoy the best possible experience with it
  • Immersive Sound from your TV Apps:  eARC (Enhanced Audio Return Channel) simplifies connectivity and supports the latest high-bitrate audio formats including Dolby Atmos®, DTS-HD Master Audio™, DTS: X®, Dolby® TrueHD.
  • Voice Control: Work with your digital assistant in any room with easy Google and Amazon Alexa SMART home ecosystem integrations
  • Stereo Height Channel Flexibility: Set the mood for your next gathering by using height or surround speakers to ensure sound is distributed evenly throughout the room. By being able to move the stereo sound to height speakers, it blankets the space more evenly, giving everyone a better experience.
  • 220 W/Ch Select Dynamic Audio Amplification (DAA) system (6 ohms, 1 kHz, 10% THD, 1 channel driven), 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2 channels driven, FTC)
  • 5.2.4-ch/7.2.2-ch Dolby Atmos® and DTS: X playback
  • Dolby Atmos Height Virtualizer and DTS Virtual: X™ 3D sound virtualization technologies
  • Stream over 5 GHz/2.4 GHz dual-band Wi-Fi®
  • Send or receive audio via bi-directional Bluetooth® wireless technology
  • Apple AirPlay 2
  • Music Made Easy with Chromecast built-in

Specifications

Power output (All channels)
220 W/Ch (6 ohms, 1 kHz, 10% THD,1-ch driven) 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)
Dynamic power
250 W (3 ohms, Front) 220 W (4 ohms, Front) 130 W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, half power)
Input sensitivity and impedance
200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM)
Rated RCA output level and impedance
1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out)
Frequency response
10 Hz–100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
Tone control
±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-noise ratio
106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
Speaker impedance
4–16 ohms
