Future Automation SPS

$15,399

Brand Future Automation

SPS

SLIDING PANEL SYSTEM

Offering the ultimate wow factor, the Future Automation SPS Sliding Panel System allows complete in-wall screen concealment at the push of a button. Enabling users to transform their viewing environment, the Sliding Panel System’s distinctively brilliant design and one of a kind functionality are sure to turn anyone’s head.

By concealing the user's TV inside the wall cavity, hidden behind a single or pair of wall panels, the SPS Sliding Panel System keeps the screen out of view when not needed while making sure it's easily and quickly available when required.

After retracting the wall panel back into the wall cavity, it is then raised up before the screen is automatically pushed out to sit flush with the surrounding wall panels.

  • Range of single panel and split panel options
  • Space efficient design
  • Wide range of cabinetry and wall design options
  • Unique functionality
  • Marine suitable as standard

THE ULTIMATE

WOW FACTOR

Precision engineering in our UK and US workshops enable super tight tolerances and a minimal shadow gap between the screen and the surround panels. Available for single panels or dual panel splitting vertically or horizontally, our range of sliding panel systems are suitable for a range of environments, including residential, corporate and marine. Control options include RS232, Contact Closure and IR as standard, with RF control available if requested.

Specifications:

PRODUCT CODE SPS800 SPS1200 SPS1300 SPS1600V SPS1800V SPS1200HZ SPS1600HZ SPS2400HZ
CONTROL OPTIONS RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE)
MARINE SUITABLE? YES YES YES YES YES YES YES YES
MAX SCREEN DIMENSIONS (H X W X D) 785 X 1400 X 100MM
(30.90 X 55.11 X 3.93")
1185 X 1700 X 100MM
(46.65 X 66.92 X 3.93")
1270 X 2100 X 100MM
(50 X 82.67 X 3.93")
1270 X 1700 X 100MM
(50 X 66.92 X 3.93")
1270 X 2100 X 100MM
(50 X 82.67 X 3.93")
900 X 1200 X 100MM
(35.43 X 47.24 X 3.93")
1400 X 1550 X 100MM
(55.11 X 61.02 X 3.93")
1400 X 2200 X 100MM
(55.11 X 86.61 X 3.93")
MOVEMENT TYPE MOTORISED MOTORISED MOTORISED MOTORISED MOTORISED MOTORISED MOTORISED MOTORISED
PANEL TYPE SINGLE PANEL SINGLE PANEL SINGLE PANEL VERTICAL SPLIT VERTICAL SPLIT HORIZONTAL SPLIT HORIZONTAL SPLIT HORIZONTAL SPLIT
