Eversolo DAC-Z6
Description
Functional overview
Dual ES9068 D\A converter chip, independent decoding for dual channel.
The 3rd generation USB XU316 with higher performance and faster speed.
High precision, low jitter dual clock oscillators synchronous processing.
Up to DSD512 Native, PCM768Hz@32Bit decoding.
Optical, Coaxial and USB support MQA full decoding and rendering.
Qualcomm QCC5125 Bluetooth 5.0 module.
Fully balanced audio architecture, differential amplifier circuit and professional calibration.
High-performance headphone amp output, 16-300 ohm headphone driver.
3-inch LCD screen, with diverse VU meter modes.
Low ripple power supply to ensure a purer power source.
Exclusive mobile phone controller APP for global control.
Specs
| Model | EverSolo DAC-Z6 |
| Display Screen | 3-inch LCD screen |
| Chassis | Aluminum Alloy |
| DAC Audio | ES 9068*2 |
| Audio Processor | USB XU316 |
| OPA Chip | RT 6863*6 |
| Power Supply | high quality switching power supply with low noise |
| Bluetooth Audio Input |
Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC Bluetooth protocol |
| USB-B DAC Input | Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA |
| USB-C DAC Input | Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA |
| OPTICAL Audio Input | Up to stereo PCM 192Khz 24Bit, DSD64 Dop,MQA |
| COAXIAL Audio Input | Up to stereo PCM 192Khz 24Bit, DSD64 Dop,MQA |
| Analog Audio Output |
Preamp output: XLR(balanced)+RCA |
| USB Port | USB2.0*1（only for firmware upgrade） |
| Control Methods | Remote control, Mobile APP control, Knob control |
| Headphone Impedance | 16-300Ω (low gain mode:16-32Ω/high gain mode:32-300Ω) |
| XLR Audio Output |
Output Level(Vrms)：4.1Vrms@0dBFS THD+N@A-wt：0.000094%@1kHz（-120dB@1kHz） THD+N@No-wt：0.000117%@1kHz（-118dB@1kHz） Noise@No-wt ：<3uVrms SNR)@No-wt：125@1kHz frequency response：20Hz-20kHz(±0.15dB) CROSSTALK：-123dB@1kHz DNR)@No-wt：125dB@1kHz |
| RCA Audio Output |
Output Level(Vrms)：2.1Vrms@0dBFS THD+N@A-wt：0.000116%@1kHz(-118dB@1kHz) THD+N@No-wt：0.000138%@1kHz(-117dB@1kHz) Noise@No-wt ：<2.5uVrms SNR)@No-wt：21dB@1kHz frequency response：20Hz-20kHz(±0.15dB) CROSSTALK：-118dB@1kHz DNR)@No-wt：121dB@1kHz |
|
Headphone (low gain mode) |
Output Level(Vrms)：1.2Vrms@0dBFS Max Power：： 45 mW@32Ω THD+N@A-wt：0.00028%@1kHz(-111dB@1kHz) THD+N@No-wt：0.00031%@1kHz(-110dB@1kHz) Noise@No-wt ：<3.5uVrms SNR)@No-wt：114dB@1kHz frequency response：20Hz-20kHz(±0.15dB) DNR)@No-wt：114dB@1kHz |
|
Headphone (high gain mode) |
Output Level(Vrms)：2.8Vrms@0dBFS Max Power： 26 mW@300Ω THD+N@A-wt：0.00014%@1kHz(-117dB@1kHz) THD+N@No-wt：0.00016%@1kHz(-116dB@1kHz) Noise@No-wt ：<3.5uVrms SNR)@No-wt：121dB@1kHz frequency response：20Hz-20kHz(±0.15dB) DNR)@No-wt：121dB@1kHz |
| Power Input | AC 110~240V 50/60Hz Max 0.35A |
| Rated power | 9W |
| Product Dimensions | 270mm(W) * 187mm(D)* 50mm(H) |
| Accessories | Remote control*1, Power cable*1, User manual*1 |
