Mobile Fidelity MasterTracker Moving Magnet Cartridge
Description
MoFi cartridges are designed by looking at where a record starts: On a cutting lathe like the model used at Mobile Fidelity Sound Lab. MasterTracker features a V-Twin dual-magnet generator that mirrors the layout of the cutting head that originally makes a record’s grooves. Employing two low-mass, powerful magnets aligned in a V formation parallel with the record grooves, MasterTracker accurately extracts music from your LPs and features stellar tracking ability.
WELL-DAMPED BILLET ALUMINUM BODY
The well-damped billet aluminum body controls resonances for tight, accurate bass reproduction. MasterTracker has the lightest-weight magnets in the Tracker Series, delivering the kind of detailed, open performance normally attributed to high-end moving-coil cartridges.
MICRO-LINE DIAMOND STYLUS
By using a Micro-Line diamond stylus shaped like the cutting head of a record lathe, MasterTracker traces vinyl groove walls with microscopic precision.
Specifications:
| Type | Dual Magnet (MM) Stereo |
| Stylus | Micro-Line |
| Output Voltage | 3mV |
| Frequency Response | 20–25,000Hz |
| Weight | 9.7g |
|
Tracking Force |
1.8–2.2g |
| Impedance | 47kOhm |
| Capacitance | 100pF |
| Compliance |
Static compliance : 40 x 10e-6/dyne Dynamic compliance : 10 x 10e-6/dyne |
| FEATURES |
• V-Twin dual-magnet generator • Micro-Line stylus with tapered cantilever • Well-damped billet aluminum body • Ohno continuous cast copper coils • 3mV output |
