AudioControl Savoy G4 Multi Channel Power Amplifier



7 Channel Power Amplifier

Built from a legacy of respected premium power amplifiers, AudioControl’s G4 series amplifiers offer effortless power  and efficiency, delivering impressively dynamic and detailed audio across all channels.


  • Award winning theater amplifier technologies
  • Seven channel home theater amplifier
  • Multi-mode operation: 7 channel, 5.1 channel, 5 channel
  • 230 watts per channel at 8 ohms; 300 watts per channel at 4 ohms
  • 600 watts at 8 ohms bridged on select channels
  • Stable into low impedances
  • Stereo/mono operation
  • Unparalleled Energy Efficiency
  • High Definition BiMOS Outputs
  • Cool Running Class H Operation
  • LightDrive Anti-Clipping Protection Circuitry
  • 5-way Binding Posts
  • Unbalanced RCA inputs with pass through
  • Balanced XLR Inputs
  • Bullet-Proof Reliability
  • Remote 12 volt Trigger
  • Perfect paired with AudioControl’s home theater preamplifiers

Incorporating AudioControl’s unique, highly efficient, and cool-running Class H design, the Savoy G4 power amplifier achieves 230 watts per channel at 8 ohms and 300 watts per channel at 4 ohms, all channels driven. The Savoy G4 can also be configured for 600 watts at 8 ohms bridged on select channels to facilitate flexible configurations well beyond powering surround channels. AudioControl’s LightDrive™ built-in anti-clipping protection circuit safely eliminates any possibility of speaker-damaging clipping and distortion, even in extreme conditions.

Designed as a perfect match to AudioControl’s preamp processors or as standalone critical listening power amplifier, the Savoy G4 can be configured for anything from a powerful 3 channel listening room to a detailed and dynamic, multichannel home theater.


Inputs 7 RCA Unbalanced, 7 XLR Balanced
Input Sensitivity 1.42 Vrms for full output
Maximum Input Voltage 2.7 Vrms
Input Impedance 100 kΩ
Amplifier Channels 7
Power Output (8Ω) 230 watts per channel
Power Output (4Ω) 300 watts per channel
Power Ouput (8Ω Bridged Mono) 600 watts
Minimum Speaker Load
Damping Factor >450
Total Harmonic Distortion 0.04% (230 watts @ 8 ohms 20 Hz-20 kHz)
Signal to Noise >102dB, A-wtd ref Full Output
Frequency Response 10 Hz -20 kHz ±1dB
Remote Power Trigger +12 VDC or Dry Contact Closure
Power Consumption (Standby) < 2W
Power Consumption (Idle) 38W
Power Consumption (loud listening level) 367W
Power Consumption (maximum) 2100W
BTU/Hour Output (Standby) 5.6 BTU/hr
BTU/Hour Output (Idle) 129 BTU/hr
BTU/Hour Output (1/8th power, loud listening level) 477 BTU/hr
BTU/Hour Output (maximum) 2507 BTU/hr
Protection clipping, short circuit, thermal, DC offset
Dimensions 17”W x 16.5”D x 5.25”H (3U)
Weight 43.0 lbs (19.5 kg)
